High precision fiber cleaver

The BC-7S fiber cleaver is high precision at a low cost, suitable for any job.

INFORMATION

Description

The BC-7S fiber cleaver is high precision at a low cost, suitable
for any job. Compact and ergonomic, precise and durable, the fiber cleaver is
perfect for all cleaving applications from Splice on Connectors to an emergency
fiber restoration. The standard FC-7S cleaves 250um and 900um fibers with a
3-step process that will fulfill any cleaving requirement. The fiber cleaver is
very popular in fiber construction project because of its high quality and good
price.

Specification

Product model	Fiber cleaver
optical fiber cladding diameter	125μm
Fiber coating diameter	0.25mm-0.9mm
Coated outer diameter	Single core
The length required to be removed before optical fiber cutting	Fiber cutting length ≥18mm
Fiber cutting length	5-20mm
Fiber cutting angle	≤0.8°
Blade life	48000 ( 1000times x 16 position x 3 high
Size	63Wx65Dx60H(mm)
Weight	280g(coffee color)/180(black color)
Fxture	Three in one multifunction jip
