10GE uplink carrier-class GPON OLT 16PON

GPON OLT 16PON is super carrier-class GPON OLT, which has high reliability and the complete security function.The 16PON OLT support 16PON ports and 2*10G uplink and 4GE combo ports.

Request price Skype WhatsApp

INFORMATION

Overview

GPON OLT 16PON is a small-capacity
cassette GPON OLT, meeting the requirements of ITU-T G.984/G.988 and
relative standards of China Telecom/Unicom GPON, with super GPON access
capacity, carrier-class reliability and the complete security function. It can
satisfy long-distance optical fiber access requirement on account of its excellent
management, maintenance and monitoring capability, abundant service features
and flexible network mode. GPON OLT 16PON can be used
with NGBNVIEW network management system so as to provide users with the
comprehensive access and perfect solution.

GPON OLT 16PON provides 16
* downlink GPON port, 4 *GE combo port and 2* 10G SFP+ port. The height is only
1U for easy installation and space saving. GPON OLT 16PON is suitable for
Broadcast three in one, video surveillance network, enterprise LAN,
Internet of Things, etc.

● 1
RU19 inch

● 1+1power
redundancy

● 16* fixed GPON port

● 4*GE
COMBO port, 2*10GE SFP+ port

● 1*console
port

Product Specification

Item	GPON OLT 16PON
Switching Capacity	140Gbps
Forwarding Capacity(Ipv4/Ipv6)	104MPPS
Service Port	16PON port, 4GE COMBO port, 2*10GE SFP+ port
Redundancy Design	Dual power supply Support AC input, double DC input and AC+DC input
Power Supply	AC: input 90～264V　47/63Hz; DC: input -36V～-72V;
Power Consumption	≤110W
Dimensions (Width x Depth x Height)	440mm×44mm×380mm
Weight (Full-Loaded)	≤5kg
Environmental Requirements	Working temperature: -10°C～55°C Storage temperature: -40°C～70°C Relative humidity: 10%～90%, non-condensing

Product Features

Item		GPON OLT 16PON
PON Features		ITU-TG.984.x standard Maximum 20 Km PON transmission distance access 128 terminals for single fiber PON Uplink and downlink triple churning encrypted function with 128Bits ONU terminal legitimacy certification, report illegal ONU registration DBA algorithm, the particle is 1Kbit/s Standard OMCI management function ONU batch software upgrade, fixed time upgrade, real time upgrade PON port optical power detection
L2 Features	MAC	MAC Black Hole Port MAC Limit 64K MAC (packet exchange chip cache 2MB, external cache 720 MB )
	VLAN	4K VLAN entries Port-based/MAC-based/protocol/IP subnet-based QinQ and flexible QinQ (StackedVLAN) VLAN Swap and VLAN Remark PVLAN to realize port isolation and saving public-vlan resources GVRP
	Spanning Tree	STP/RSTP/MSTP Remote loop detecting
	Port	Bi-directional bandwidth control Static link aggregation and LACP(Link Aggregation Control Protocol) Port mirroring
Security Features	User’s Security	Anti-ARP-spoofing Anti-ARP-flooding IP Source Guard create IP+VLAN+MAC+Port binding Port Isolation MAC address binding to the port and MAC address filtering IEEE 802.1x and AAA/Radius authentication
	Device Security	Anti-DOS attack(such as ARP, Synflood, Smurf, ICMP attack), ARP detection, worm and Msblaster worm attack SSHv2 Secure Shell SNMP v3 encrypted management Security IP login through Telnet Hierarchical management and password protection of users
	Network Security	User-based MAC and ARP traffic examination Restrict ARP traffic of each user and force-out user with abnormal ARP traffic Dynamic ARP table-based binding IP+VLAN+MAC+Port binding L2 to L7 ACL flow filtration mechanism on the 80 bytes of the head of user-defined packet Port-based broadcast/multicast suppression and auto-shutdown risk port URPF to prevent IP address counterfeit and attack DHCP Option82 and PPPoE+ upload user’s physical location Plaintext authentication of OSPF, RIPv2 and BGPv4 packets and MD5 cryptograph authentication
Service Features	ACL	Standard and extended ACL Time Range ACL Flow classification and flow definition based on source/destination MAC address, VLAN, 802.1p, ToS, DiffServ, source/destination IP(IPv4/IPv6) address, TCP/UDP port number, protocol type, etc packet filtration of L2～L7 deep to 80 bytes of IP packet head
	QoS	Rate-limit to packet sending/receiving speed of port or self-defined flow and provide general flow monitor and two-speed tri-color monitor of self-defined flow Priority remark to port or self-defined flow and provide 802.1P, DSCP priority and Remark CAR(Committed Access Rate), Traffic Shaping and flow statistics Packet mirror and redirection of interface and self-defined flow Super queue scheduler based on port or self-defined flow. Each port/ flow supports 8 priority queues and scheduler of SP, WRR and SP+WRR. Congestion avoid mechanism, including Tail-Drop and WRED
	IPv4	ARP Proxy DHCP Relay DHCP Server Static Routing RIPv1/v2 OSPFv2 ECMP PBR
	IPv6	ICMPv6 ICMPv6 Redirection DHCPv6 ACLv6 Dual stack of IPv6 and IPv4
	Multicast	IGMPv1/v2/v3 IGMPv1/v2/v3 Snooping IGMP Filter MVR and cross VLAN multicast copy IGMP Fast leave IGMP Proxy PIM-SM/PIM-DM/PIM-SSM MLDv2/MLDv2 Snooping
Reliability	Loop Protection	ERRP or ERPS Loopback-detection
	Link Protection	FlexLink (recover-time <50ms) RSTP/MSTP (recover-time <1s) LACP (recover-time <10ms) BFD
	Device Protection	VRRP host backup 1+1 power hot backup
Maintenance	Network Maintenance	Port real-time, utilization and transmit/receive statistic based on Telnet RFC3176 sFlow analysis LLDP GPON OMCI RFC 3164 BSD syslog Protocol Ping and Traceroute
Maintenance	Device Management	CLI, Console port, Telnet; SNMPv1/v2/v3 RMON (Remote Monitoring)1,2,3,9 groups MIB NTP NGBNView network management
