500mW Outdoor High-Power Outdoor Wireless Access Point

BD-OS2C2D-833 outdoor Access Point is a high power Outdoor dual band ceiling type AP, provide 2.4G and 5G terminal access with the maximum 1.2Gbps rate. It supports POE 48V power , The power of the AP is up to 500mW, with high gain directional antenna, it can cover a large scope with high bandwidth and stability. The device design with cast Aluminum enclosures, fully compliant with IP67 and waterproof standard, It can work at -40 to 65 degrees wide temperature environment.

Request price Skype WhatsApp

INFORMATION

Overview

The device design with cast Aluminum enclosures, fully compliant with IP67 and waterproof standard, It can work at -40 to 65 degrees wide temperature environment.

Futures

í Max speed of wireless is1.2Gbps;

í built-in 2*2MIMO ;

í Support Gigabit SFP

í High RF power output, up to 500mW;

í Support Telnet and WEB management;

í Support 802.11a/b/g/n/ac technical standard;

í High-sensitivity, meets technical standard of operators;

í supports 48V POE reverse power ;

í Waterproof, anti-dust, anti-ultraviolet, wide temperature and IP67 protection standards design to meet the various outdoor environment;

í Support 4G LTE and built-in storage (SSD and SD card compatible design)

Specification

Item	parameter	specification
RF	Operating frequency	2.4GHz/5GHz
	Wireless standard	IEEE802.11ac/a/b/g/n MIMO 2×2
	TX power	í 6-54Mbps:27dBm í MCS0:27dBm í MCS7:27dBm í MCS9 :24dBm
	Receiver Sensitivity	í 21Mbps :-97dBm í 11Mbps :-91dBm í 6Mbps: -95dBm í 54Mbps:-78dBm í MCS0-HT20:-90dBm í MCS7-HT20:-73dBm í MCS0-HT40:-87dBm í MCS7-HT40:-71dBm
Software features	Network function	í Support AP, STA mode í Support user isolation í Support signal scanning í Support bandwidth limit í Support Portal authentication í Support blacklist and white list í Support prevent ARP Spoof attack í Support for illegal AP detection í Support AC management í Support power adjustment í Support VLAN
	Management function	í Support WEB configuration management í Support SNMPv2 í Support Telnet CLI í Support remote and batch software upgrade í Support FTP, TFTP í Support Remote Syslog í Support console port configuration and debugging
	certificate and security functions	í WPA/WPA2（WPA-PSK，WPA-EAP） í WEP 64/128 bit encryption í MAC encryption í Standard RADIUS server interface, channel support AES encryption
Environment Parameters	Power supply	48V POE power supply
	Dimensions	239mm（H）195mm（W） 83mm（D）
	Weight	2Kg
	WAN Interface	í 1 SFP slot for GE SFP transceivers í 1*10/100/1000Base-Tx (combo with SFP port)
	Other port	SIM card, RS232 and SD card
	Antenna type	Optional built-indirectional antennas or outdoor external antennas (4 N Type RF connectors)
	power consumption	25W（typical）30W（Maximum）
	Waterproof grade	IP67
	System memory	256M
	FLASH	16M
	Operating temperature	-40~55∩
	Humidity	5-95％ (non-condensing)
	Storage temperature	-40~85∩
