1FE industrial fiber media converter

INFORMATION

OVERVIEW

The BD-S201FI series
is an industrial Ethernet fiber switch/media converter ,with 1*10/100M Ethernet ports, Users can select different optical modules according to their needs,
such as multi-mode dual fiber and single-mode dual fiber, single-mode single
fiber, etc. It uses the latest IC in the United States, with stable
performance, high quality and high cost performance. It is suitable for
industrial scenes such as intelligent transportation, rail transit, electric
power, mining, metallurgy and green energy construction to form a
cost-effective and stable communication network.

Unmanaged model, plug and play, no configuration, easy to use.

FEATURE

n 10/100M Combo port, Fast Ethernet

◇ All
series support “10/100M Ethernet port + SC port” combination, It is
convenient for users to set up networking to meet the network requirements of
various scenarios.

◇ Support
non-blocking wire speed forwarding .

◇ Support
full duplex based on IEEE802.3x and half duplex based on backpressure .

n The Equipment Is Stable And Reliable

◇ The host has low power consumption, no fan mute
design, aluminum alloy metal shell, excellent heat dissipation, and ensure
stable operation of products.

◇ The equipment fully meets the requirements of
3C, CE, FCC and RoHS safety regulations, and is safe and reliable.

◇ The user can easily understand the working status
of the device through the power indicator (PWR), port status indicator
(Link/Act), and POE operation indicator.

TECHNICAL SPECIFICATION

Model	BDS31021F-M	BDS31021F-S	BDS31021FS-W
Interface	110/100Base-TX（Data）1155M uplink SC port (Data)
Network Protocol	IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u 100Base-TX/FX;IEEE802.3x
Ethernet Port Feature	10/100/1000BaseT (X) automatic detection, full / half duplex MDI/MDI-X adaptive
SFP Port	155Mbps,multi-mode dual fiber SC port	155Mbps,single-mode dual fiber SC port	155Mbps,single-mode single fiber SC port
Forwarding Mode	Store and Forward(Full Wire Speed)
Switching Capacity	1.2Gbps
Forwarding Rate@64byte	0.3Mpps
MAC	2K
Buffer Memory	768K
Twisted Pair Transmission	10BASE-T：Cat3,4,5 UTP(≤100 meter) 100BASE-TX：Cat5 or later UTP(≤100 meter)
Optical Cable / distance	multi-mode 850nm 0~550M, 1310nm 0~2KM	single-mode 1310nm 0~40KM, 1550nm 0~120KM
Total PWR / Input Voltage	4W/(12-48VDC)
Power Consumption	Standby:<1W;Full load:<4W
LED	Power Indicator Light: PWR (Green);Network Indicator: Link/Act (Yellow); SFP Indicator: L/F (Green); POE Work Indicator: POE (Green)
Operation TEMP / Humidity	-40~+80°C;5%~90% RH Non condensing
Storage TEMP / Humidity	-40~+85°C;5%~95% RH Non condensing
Dimension（LWH）	11910030mm
Net /Gross Weight	<0.4kg / <0.7kg
Installation Method	desktop type、35mm DIN Rail type
Lightning protection / protection level	Port Lightning protection :4KV 8/20us; Protection Level:IP40 IEC61000-4-2(ESD)±8kV Contact Discharge,±15kV Air Discharge IEC61000-4-3(RS)10V/m (80~1000MHz) IEC61000-4-4(EFT)Power Line: ±4kV; Data Line: ±2kV IEC61000-4-5(Surge)Power Line,CM±4kV/DM±2kV;Data Line,±4kV IEC61000-4-6 (Radio Frequency Conduction) 10V(150kHz~80MHz) IEC61000-4-8 (Power Frequency Magnetic Field) 100A/m Continued; 1000A/m,1s to 3s IEC61000-4-9 (Pulsed Magnetic Field) 1000A/m IEC61000-4-10 (Damping Oscillation) 30A/m ,1MHz IEC61000-4-12/18 (SHOCKWAVE) CM 2.5kV, DM 1kV IEC61000-4-16 (Common Mode Conduction) 30V Continued; 300V,1s FCC Part 15/CISPR22(EN55022)Class B IEC61000-6-2(General Industry standard)
Mechanical properties	IEC60068-2-6 (anti vibration) IEC60068-2-27 (anti shock) IEC60068-2-32 (free fall)
Certification	3C;CE mark, commercial;CE/LVD EN60950;FCC Part 15 Class B;RoHS;
Warranty	5 years, lifelong maintenance.
