INFORMATION
Features
● Wavelength selectable to C-band ITU-T grid wavelengths
● Suitable for use in 100GHz channel spacing DWDM systems
● XFP MSA Compliant
● data rate from 9.95 Gbps to 11.1Gbps
● No Reference Clock required
● Cold Start up Wavelength Compliance
● DWDM-rated EML transmitter and APD receiver
● link length up to 80km
● Low Power Dissipation 3.5W Maximum
● -5oC to 70oC Operating Case Temperature
● Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power
● RoHS compliant and lead free
Absolute Maximum Ratings
|
Parameter |
Symbol |
Min |
Max |
Unit |
|
Supply Voltage 1 |
Vcc3 |
-0.5 |
4.0 |
V |
|
Supply Voltage 2 |
Vcc5 |
-0.5 |
6.0 |
V |
|
Storage Temperature |
Tst |
-40 |
85 |
oC |
|
Optical Input Received Power |
PIN |
– |
+4 |
dBm |
Operating Conditions
|
Parameter |
Symbol |
Min |
Typical |
Max |
Unit |
|
Supply Voltage 1 |
Vcc3 |
3.13 |
3.3 |
3.47 |
V |
|
Supply current 1 |
Icc3 |
|
|
750 |
mA |
|
Supply Voltage 2 |
Vcc5 |
4.75 |
5 |
5.25 |
V |
|
Supply current 2 |
Icc5 |
|
|
500 |
mA |
|
Operating Case temperature |
Tca |
-5 |
– |
70 |
oC |
|
Module Power Dissipation |
Pm |
– |
|
3.5 |
W |
Transmitter Specifications – Optical
|
Parameter |
Symbol |
Min |
Typical |
Max |
Unit |
|
Data Rate Multirate |
Mra |
9.95 |
– |
11.3 |
Gbps |
|
Center Wavelength (SOL)△ |
lc |
lc -25 |
lc |
lc +25 |
pm |
|
Center Wavelength (EOL)▲ |
lc |
lc -100 |
lc |
lc+100 |
pm |
|
Optical Transmit Power |
|
-1 |
– |
+4 |
dBm |
|
Optical Transmit Power (disabled) |
PTX_DISABLE |
– |
– |
-40 |
dBm |
|
Extinction Ratio |
ER |
8.2 |
|
– |
dB |
|
Channel Spacing |
∆f |
– |
100 |
– |
GHz |
|
Jitter Generation |
TJP-P |
– |
– |
0.1 |
UI |
|
Spectral Width (-20dB) |
Dl20 |
– |
0.1 |
0.3 |
nm |
|
Side Mode Suppression Ratio |
SMSR |
30 |
– |
– |
dB |
|
Dispersion penalty(800ps/nm) |
DP |
|
|
2 |
dB |
|
Eye Mask |
Compliant with ITU-T G.691 STM-64 eye mask |
||||
△Laser- Start of Life
▲Laser End of life
C-band λc Wavelength Guide
|
ITU Channel Product Code |
Frequency(THz) |
Wavelength |
ITU Channel Product Code |
Frequency(THz) |
Wavelength |
|
17 |
191.7 |
1563.86 |
40 |
194.0 |
1545.32 |
|
18 |
191.8 |
1563.05 |
41 |
194.1 |
1544.53 |
|
19 |
191.9 |
1562.23 |
42 |
194.2 |
1543.73 |
|
20 |
192.0 |
1561.42 |
43 |
194.3 |
1542.94 |
|
21 |
192.1 |
1560.61 |
44 |
194.4 |
1542.14 |
|
22 |
192.2 |
1559.79 |
45 |
194.5 |
1541.35 |
|
23 |
192.3 |
1558.98 |
46 |
194.6 |
1540.56 |
|
24 |
192.4 |
1558.17 |
47 |
194.7 |
1539.77 |
|
25 |
192.5 |
1557.36 |
48 |
194.8 |
1538.98 |
|
26 |
192.6 |
1556.55 |
49 |
194.9 |
1538.19 |
|
27 |
192.7 |
1555.75 |
50 |
195.0 |
1537.40 |
|
28 |
192.8 |
1554.94 |
51 |
195.1 |
1536.61 |
|
29 |
192.9 |
1554.13 |
52 |
195.2 |
1535.82 |
|
30 |
193.0 |
1553.33 |
53 |
195.3 |
1535.04 |
|
31 |
193.1 |
1552.52 |
54 |
195.4 |
1534.25 |
|
32 |
193.2 |
1551.72 |
55 |
195.5 |
1533.47 |
|
33 |
193.3 |
1550.92 |
56 |
195.6 |
1532.68 |
|
34 |
193.4 |
1550.12 |
57 |
195.7 |
1531.90 |
|
35 |
193.5 |
1549.32 |
58 |
195.8 |
1531.12 |
|
36 |
193.6 |
1548.51 |
59 |
195.9 |
1530.33 |
|
37 |
193.7 |
1547.72 |
60 |
196.0 |
1529.55 |
|
38 |
193.8 |
1546.92 |
61 |
196.1 |
1528.77 |
|
39 |
193.9 |
1546.12 |
|
|
|
