INFORMATION

Model:  B02S-ISDBT

Hardware

CPU
Mstar7805/Sunplus 1508A

Memory
32X16Mbit DDR2 Frequency1066

Flash 32M
bytes

Demodulator
Type ISDB SOC Chip Set

TUNER Rafael
R836

Front Panel
USB 2.0 Embedded One Host,

 4-digit LED display on front panel

 red LED Standby,green LED Lock

 Panel KEY, POWER, CH+ ,CH-

Rear Panel
Tuner RF input connector   EC-type
IEC169-2 Female

 Tuner RF Loop through connector   IEC-type IEC169-24 Male

 HD V1.3/V1.4

 RCA CVBS AL AR Connector x1

 Ypbpr RCAx1

 Coaxial x1

 Power AC100~240V 50Hz/60Hz

Demodulation

Terrisal
Receiver Standard ISDB-T broadcast (1, 3, 13 segment)

Input RF
Frequency VHF:177.143~213.143 MHz:UHF 473.143~803.143MHz.

Bandwidth
6MHz

Demodulatio
QPSK / 16QAM / 64QAM/QPSK or DQPSK

FEC 1/ 2, 2/3,
3/4, 5/6, 7/8 Automatic

Guard Interval
1/4,1/8,1/16,1/32

FFT Mode 2K/
8K/32K

Input level -83 – -5dBm

Sortware Features

•Used for any ISDB-T countries like Brazil, Peru,
Argentina,Chile,Venezuela,Philippines.Ecuador

•Supports all ISDB-T broadcast (1, 3, 13 segment),
MPEG-2/MPEG-4 AVC/H.264 HD/SD Video , DiVX compliant

•Support 3D interface

•Support teletext/subtitle/muti-language

•Supported 7-Day EPG function, VBI Teletext

•AUTO, 16:9 Pillar Box, 16:9 Pan G Scan, 4:3 Letter Box, 4:3
Pan G Scan, 4:3 Full, 16:9 Wide Screen

•USB 2.0 for PVR,TIMESHIFT,software upgrade and media files
playback

•Video output resolution:
480i/576i/480p/576p/720p/1080i/1080P

Decoder

Video Decoder
Compliant with: MPEG-4 part10/MPEG-2 ISO/IEC 13818

MPEG-4 Simple/Main/Advanced
Profile@LEVEL3(10Mbps)

MPEG-2 Main
Profile# Main Level(15Mbps)

H.264
MP#L3(10Mbps).H.264 HP L4.1(25Mbps)

Audio Decoder
MPEG-1, MPEG-2 (Layer I/II), MP3, AC-3 (Do-by Digital), AAC-LC, WMA

E-AC-3 (Do-by
Digital Plus) decoding HE-AAC 5.1 multi-chhannel decoding

Powerful Multimedia Features

MediaCodec
avi. mpg, .dat, .vob, .div, .mov, .mkv, .jpeg, .ts etc

Audio Codec
WMA,MP3,AAC (.wma,.mp3,m4a)

Photo Codec JPEG, BMP, PNG

License

Optional DTS, Do-by Digital, Do-by Digital Plus, RM/RMVB, Divx License

Accessories

Accessories gift box
